Structure of MHHPA CAS 25550-51-0

MHHPA CAS 25550-51-0

Identification
Properties
Safety Data
Specifications & Other Information
Links

Identification

CAS Number

25550-51-0

Name

MHHPA

Synonyms

1,3-Isobenzofurandione, hexahydro-3a-methyl- [ACD/Index Name]
1,3-Isobenzofurandione, hexahydromethyl-
255-853-3 [EINECS]
256-356-4 [EINECS]
3a-Methylhexahydro-2-benzofuran-1,3-dion [German] [ACD/IUPAC Name]
3a-Methylhexahydro-2-benzofuran-1,3-dione [ACD/IUPAC Name]
3a-Méthylhexahydro-2-benzofurane-1,3-dione [French] [ACD/IUPAC Name]
hexahydromethylphthalic anhydride
Methylhexahydrophthalic Anhydride
1,3-Isobenzofurandione, hexahydro-3a-methyl-, cis-
2,3,5,6-tetrahydro-2-methylphthalic anhydride
25550-51-0 [RN]
3a-Methyl-3a,4,7,7a-tetrahydroisobenzofuran-1,3-dione
3a-methylhexahydroisobenzofuran-1,3-dione
7a-methyl-4,5,6,7-tetrahydro-3aH-2-benzofuran-1,3-dione
AGN-PC-0JCZ6J
AGN-PC-0O3DJT
CHEBI:55461
hexahydro-1-methylphthalic anhydride
Hexahydro-4-Methylphthalic Anhydride
hexahydromethyl-1,3-isobenzofurandione
methyl hexahydrophthalic anhydride
METHYL-1,2-CYCLOHEXANEDICARBOXYLIC ANHYDRIDE
methylhexahydroisobenzofuran-1,3-dione
methylhexahydrophthalic anhydride,98%
methylhexahydrophthalicanhydride
MFCD22690873
MHHPA
phthalic anhydride, methylhexahydro-

Molecular Structure

Structure of MHHPA CAS 25550-51-0

Structure of MHHPA CAS 25550-51-0

SMILES

CC12CCCCC1C(=O)OC2=O

StdInChI

InChI=1S/C9H12O3/c1-9-5-3-2-4-6(9)7(10)12-8(9)11/h6H,2-5H2,1H3

StdInChIKey

VYKXQOYUCMREIS-UHFFFAOYSA-N

Molecular Formula

C9H12O3

Molecular Weight

168.190

EINECS

255-853-3

Properties

Appearance

Colorless transparent liquid

Refractive Index

n20/D 1.4750

Boiling Point

137℃/1.3hPa

Specific gravity

1.162@25℃

Viscosity

30-50mPa.s@25℃

Density

1.085 g/mL at 25 °C(lit.)

Safety Data

WGK Germany

3

Specifications and Other Information of Our MHHPA CAS 25550-51-0

Standard

Enterprise standard

Package

25 kg or 200 kg plastic drums

Storage

Store in a moisture-proof, fire-proof, waterproof, storage in a dry and ventilated warehouse.

Application

1.Epoxy resin curing agent: MHHPA is a heat curing type acid anhydride curing agent. It is mainly used in electrical and electronic fields. It has good high temperature and electrical performance. It can be used for the immersion of electrical equipment coils and the casting of electrical components and semiconductor sealing. Casting outdoor insulators, light-emitting diodes (LEDs), ignition coils, special-purpose capacitors, transformers, motors, sports and entertainment equipment, etc., which are required to resist outdoor ultraviolet light and moisture resistance.
2.Epoxy composites: in combination with fiber reinforcement in lamination, centrifugal casting, pultrusion, etc., such as pressure cylinders, pressure pipes, fishing rods, golf clubs, etc.
3.Adhesive: The refractive index of alicyclic epoxy adhesive made of MHHPA is similar to that of optical glass. It has small internal stress after curing, high bonding strength, no discoloration and aging resistance. It is suitable for bonding large-area optical parts.
