Low temperature electrolyte
Name
Low temperature electrolyte
Specifications and Other Information of Our Low temperature electrolyte
Detailed Specification
Grade 1
| Electrolyte grade | WI62 | ||
| Warranty period | 6 months(Unopened) | Cathode material | LCO,NCM |
| Solvent composition | EC/EMC/DMC/EA | Anode material | Artificial graphite |
| Moisture content | ≤15ppm | Cycle performance | After 300 Cycles, the capacity retention is more than 85%, and after 500 cycles; the capacity retention is more than 85% |
| Acidity content | ≤50ppm | Applicable battery | Soft package, Aluminum shell |
| Density | >1,10g/mL | Low temperature performance | Under-10℃ and for 16 hours, Capacitance play is more than 70% at 0.2C |
| Conductivity | 11.0-13.0ms/cm | Low temperature performance | After 1000 Cycles, the capacity retention 60% at 0.2C Under-40℃ |
| Chroma | ≤50Hazen | ||
Grade 2
| Electrolyte grade | WI06 | ||
| Warranty period | 6 months(Unopened) | Cathode material | NCM,LMO+NCM |
| Solvent composition | EC/DMC/EMC | Anode material | Artificial graphite |
| Moisture content | ≤15ppm | Cycle performance | After 300 cycles the capacity retention is more than 85%, and after 500 cycles the capacity retention is more than 80% |
| Acidity content | ≤50ppm | Applicable battery | Soft package, Aluminum shell |
| Density | >1,25g/mL | Low temperature performance | Under-30℃ and for 16 hours, Capacitance play is more than 70% at 0.2C |
| Conductivity | 10.0-12.0ms/cm | High temperature performance | Under 60℃ for 7 days with full charge, the expansion rate is less than 5% |
| Chroma | ≤50Hazen | Safety | The battery does not smoke, fire, explode under 3C 10V overcharge and acupuncture |
Advantage
This series of electrolyte is mainly used for LCO, LMO, NCM and anode materials is composite graphite, artificial graphite. The electrolyte is suitable for cylinder, soft package and aluminum shell battery which has good low temperature performance.
