HAT-CN CAS 105598-27-4
Identification
CAS Number
105598-27-4
Name
HAT-CN
Synonyms
1,4,5,8,9,11-Hexaazatriphenylenehexacarbonitrile
105598-27-4 [RN]
Dipyrazino[2,3-f:2′,3′-h]chinoxalin-2,3,6,7,10,11-hexacarbonitril [German] [ACD/IUPAC Name]
Dipyrazino[2,3-f:2′,3′-h]quinoxaline-2,3,6,7,10,11-hexacarbonitrile [ACD/Index Name] [ACD/IUPAC Name]
Dipyrazino[2,3-f:2′,3′-h]quinoxaline-2,3,6,7,10,11-hexacarbonitrile [French] [ACD/Index Name] [ACD/IUPAC Name]
HAT-CN6
MFCD19689401
[105598-27-4] [RN]
1,4,5,8,9,12 -Hexaaza-triphenylene-2,3,6,7,10,11-hexacarbonitrile
1,4,5,8,9,12-HEXAAZATRIPHENYLENE-2,3,6,7,10,11-HEXACARBONITRILE
1,4,5,8,9,12-HEXAAZA-TRIPHENYLENE-2,3,6,7,10,11-HEXACARBONITRILE
1,4,5,8,9,12-hexaazatriphenylenehexacarbonitrile
2,3,6,7,10,11-Hexacyano-1,4,5,8,9,12-hexaazatriphenylene
2-[(3R,6S,12S,20R,23S)-20-carbamoyl-12-[4-(diaminomethylideneamino)butyl]-3-(1H-indol-3-ylmethyl)-2,5,8,11,14,22-hexaoxo-17,18-dithia-1,4,7,10,13,21-hexazabicyclo[21.3.0]hexacosan-6-yl]acetic acid acetate;Eptifibatide
‘Dipyrazino[2,3-f:2”,3”-h]quinoxaline-2,3,6,7,10,11-hexacarbonitrile’
Dipyrazino[2,3-f:2′,3′-h]quinoxalinehexacarbonitrile
Eptifibatide [INN] [Wiki]
Hexaazatriphenylenehexacabonitrile
SMILES
C(#N)C1=C(N=C2C(=N1)C3=NC(=C(N=C3C4=NC(=C(N=C24)C#N)C#N)C#N)C#N)C#N
StdInChI
InChI=1S/C18N12/c19-1-7-8(2-20)26-14-13(25-7)15-17(29-10(4-22)9(3-21)27-15)18-16(14)28-11(5-23)12(6-24)30-18
StdInChIKey
DKHNGUNXLDCATP-UHFFFAOYSA-N
Molecular Formula
C18N12
Molecular Weight
384.273
EINECS
MFCD19689401
Properties
Appearance
Light-yellow powder
Safety Data
RIDADR
NONH for all modes of transport
WGK Germany
3
MSDS Download
Specifications and Other Information of Our HAT-CN CAS 105598-27-4
Specifications and Other Information of Our HAT-CN CAS 105598-27-4
Identification Methods
HNMR, HPLC
Purity
99% min
Shelf Life
2 years
Storage
Under room temperature away from light
Known Application
Used as intermediates for OLED materials.
Product Description
Hexaazatriphenylenehexacarbonitrile (HAT-CN) is an organic small molecule with high electron affinity and hole-transporting properties. It was first synthesized by Japanese chemist Nagao Kobayashi in 2001.
HAT-CN is composed of six benzene rings connected by nitrogen atoms and six cyano groups. This structure gives HAT-CN excellent electron transport properties, making it widely used in the manufacture of organic electronic and optoelectronic devices. For example, HAT-CN can be used as an organic semiconductor material to fabricate organic field-effect transistors, organic light-emitting diodes, and organic solar cells.
The main application of HAT-CN is as an organic semiconductor material, and it has several advantages:
- High electron mobility: HAT-CN has high electron mobility, making it an excellent performer in organic field-effect transistors and organic light-emitting diodes.
- Good hole-transporting properties: HAT-CN also has good hole-transporting properties, making it suitable for high-efficiency organic solar cells.
- Solubility: HAT-CN is soluble in common organic solvents, making its preparation and processing very convenient.
Therefore, HAT-CN is a very promising organic semiconductor material that can be used to manufacture various high-performance organic electronic devices.
General View of Documents
TGA of HAT-CN CAS 105598-27-4
